Machine occupied area：3,100×850×1,750（L×W×H）mm for 4 spindles.
These 4 spindles are taken as reference,adding 1,900 mm for each additional
4 spindles,no change for width and height.
Weight：1,000KG,1,100KG(6 spindles)
Automatic tension control
Control mode：single spindle control,the freq.con.or stepless controller is used for cabbage rotational motor in drying room.The yarn guide cylinder is traced by the servo.
Motor power
0.18kw per spindle(cabbage motor),0.75kw per spindle (yarn guide cyl.motor),1.8kw per spindle (drying room),about 1.1kw per spindle (heat cyclic motor),sizing pump motor 0.75kw,size trough heating 3kw.
TECHNICAL PARAMETER PERFORMANCE INDEX
Spindle number：2,4,8,12
Speed：20～300 meters per min.(Depending on the yarn thread sorts)
Yarn range and applicable sort:5～500tex,cotton,wool,silk,hemp and chemical fabric,etc.
Length counted mode：electronic,speed displayed in LCD
